Uniforest Forestry Winches PROFI – SERIES G

Forestry winches PROFI

In addition to a tractor, the PROFI forestry winches for professional use are essential machines required for daily timber harvesting from the forest, Using these winches, the work is safer, easier and quicker.

Our PROFI winches are distinguished by the patented solutions, reducing the strain on the operator and underling the technological superiority of the machines.

They were designed to ensure simple maintenance, with a compact and stable framework and mechanisms for energy efficiency.

The long service life of PROFI winches is now beyond question.

The G Series is our first group of PROFI forestry winches, which has been on the market for more than 10 years. Their specialty is the drive through a gear transmission, which provides low maintenance costs and long service life.

The forestry winch 2×85 G is a double drum forestry winch with a pulling force of 8.5t.

Forestry winch 2×85 G has two independent hydraulic systems for each drum with pulling force of 8.5t separately. It enables safe work, as the winch is positioned closer to the tractor, and the pulley is fixed lower, which puts the centre of gravity of the winch lower. Therefore, there is less chance for the tractor to be lifted. Each drum has an extra large drum capacity, which allows more wound up wire rope. For easy work there are large storage places (PATENT) on the front of the winch, that the dirt from the wheels of the tractor does not get between the chain and other equipment. In order to facilitate the manipulation and stacking of logs, there is also a hydraulic hinged butt plate.

  • SMART 3-in-1 AUTO STOP function (limit switch)
  • Unwinding device
  • Independent hydraulic system for each drum
  • Convenient positioning
  • Maxi drum
  • Large storage spaces in front of winch
  • Plenty of storage area for additional equipment
  • Drive over bevel helical and spur gears
  • Hydraulic hinged butt plate
  • Foldable window guard



Description

Description

Technical Specifications:
65G 2 x65G 85G 2X85G 85GF 120G power
Drive kN Helical and bevel gear drive Helical and bevel gear drive Worm gear Worm gear Worm gear Worm gear
Pulling Force kN 65/40 65/40 85/56 85/56 85/56 120/80
Brake force kN 81 81 106 106 106 150
Wire rope medium speed m/s 0.65 (540rpm) 0.65 (540rpm) 0.5 (540rpm) 0.5 (540rpm) 0.5 (540rpm) 0.5 (540rpm)
Drum capacity length/diameter m/mm 130/12 130/12 118/13 118/13 118/13 –
160/11 160/11 130/12 130/12 130/12 140/14
Recommended tractor power (kW/HP) 60/80 74/100 74/100 74/100 74/100 88/120
Clutch plates pcs 4 4 6 6 6 8
Pump type Gear Pump Gear Pump 3-piston pump Gear Pump Gear Pump Gear Pump
PTO speed rpm 750 750 750 750 750 750
Oil pressure mm 110-150 110-150 110-150 110-150 110-150 110-150
Standard butt plate dimensions mm 1720 1920 1920 1920 1920 1920
Optional butt plate dimensions mm 1920/2100 – 2100 – – –
1920mm hydraulic hinged butt plate
Optional
–
Optional
– – –
2100mm Hydraulic hinged butt plate
Optional
Optional
Optional
Optional
Optional
–
2400mm hydraulic hinged butt plate – – – – –
Optional
Depth of winch mm 840 840 930 930 930 970
Height of winch- excluding guard mm 1500 1500 1500 1500 1500 1500
Height of winch including guard mm 2300 2300 2300 2300 2300 2300
Weight without wire rope 1720mm kg 620 – – – – –
Weight without wire rope 1920mm kg 660 900 680 970 680 930
Weight without wire rope 2100mm kg 700 980 720 1145 720 1110
Unwinding device
Standard
Standard
Standard
Standard
Standard
Standard
Wire rope guide
Standard
Standard
Standard
Standard
Standard
Standard
Auto stop function
Optional
Optional
Optional
Optional
Optional
Standard
Smart 3in1
Optional
Optional
Optional
Optional
Optional
–
Adjustable braking force – – – – –
Standard
Key Features:
  Smart 3in1

(1) When pulling logs with a tractor, you may encounter some obstacles on the road (hill, roots etc.). If the tractor is not able to overcome these obstacles, the unwinding function can be switched into the mode without the assistance of the unwinding device and you can continue driving with a taught wire rope between the winch and the load. (2) The unwinding device can be turned on and off without delay (the standard model has a 1.5 sec. delay). (3) The SMART 3in1 function ensures additional tension of the wire rope between the unwinding pulley and drum. This function is only available with the remote controls Teleradio, Terra funk and manual console.

  Unwinding Device and auto stop

To make the wire rope unwinding easier you can choose a winch with an integrated unwinding device. This type of winch also guarantees a constant tension of the wire rope between the unwinding pulley and the drum, thus preventing damage to the drum or pulley and enabling a longer service life. AUTO STOP function (limit switch) automatically stops the function of winding the wire rope on the drum. This function prevents mechanical damages of the unwinding device, entanglement and wire rope damages.

  Multi-Plate Clutch

Heavy Duty multi-plate clutch assemblies for long life

  Heavy Duty Gear drives

Worm, Bevel-helical & spur gear drive systems for energy efficiency and increased durability

  Heavy Duty Unwinding and top Roller

Pivoting top roller ensures optimal positioning for the pulling direction
