KM 25060 H – Rear Mounted Sweeper for Tractor 250cm Hydraulic

The KM60 range sport even more robust construction techniques than our KM45 sweepers, with CNC folded and welded, heavy For tractors 60 – 150hp

  • Hydraulic drive (50 litres/min)
  • Inboard hydraulic motor with self adjusting duplex chain to brush
  • Substantial steel folded frame construction
  • Brush diameter 60cm
  • 2 heavy duty support wheels 200x80mm with individual lever height adjustment
  • Angling left and right on 400mm bearing
  • Multi function hydraulic valve block with flow control valve, relief valve, overrun protection and auto collector opening.
  • Paint RAL 2011 (Orange)
  • Supplied with 2 section, 5 row Combi brush

Requires ABR 60 Bracket to attach to tractor

Description

Description

This is our larger mid‐size range of professional, heavy duty sweepers with hydraulic drive and manual angling. The Mounting frame gives incredible support to the sweeper with the weight going through the sweeper from the top 400mm bearing where it is strongest.

The KM 60 range sport even more robust construction techniques in common with the Kersten sweeper range. A robust sweeper 250cm Width with CNC folded and welded, heavy gauge steel. An inboard variable speed hydraulic drive motor, with constant tension duplex drive chain allows greater power to the brush and negates chain slippage.

Our Ø 60cm, five row combi brush moves large, heavy debris with ease. Sweeping height is finely adjusted by heavy duty gauge wheels—each wheel is adjusted individually for precise positioning of the brush.

Suitable for Front and Rear 3 point linkage CAT 1 and CAT 2, Front Loaders, Telehandlers and large Forklift trucks.

Diameter  60cm
Width  250cm
Oil Flow  50l/m
Series   KM60
