Description
The KM 45 Series is a versatile sweeper with big performance in a light weight, strong compact chassis. Optional accessories include front collector box, gulley brushes and front brush guard. When choosing the correct sweeper for your application you should consider the width of the power unit, oil flow or PTO horsepower available to power the sweeper and capacity to lift the sweeper, with a full collector if required.
It will fit a wide variety of applications, including; John Deere Quick-Tach for X-series and 1026, Kubota B1220 , Kubota G23 – G26 with Kersten front Linkage, Cat 1 linkage A-frames for front linkages, Cat 1 front 3 point linkage systems, Outfront Mowers with 2 point lift arms, Ransomes HR300, Kubota RTV.
Our Sweepers are fitted with a large diameter 5 row stiff spiral brush for moving large debris and dirt. The pendulum suspension system protects the sweeper and carrier from damage over rough ground. Sweeping height is adjusted by heavy duty gauge wheels — each wheel is adjusted individually for precise positioning of the brush. The sweeper is geared for low speed, high torque applications, such as removing soil in block paving or tarmac. However, we can change this on request, to suit other applications where lighter material must be moved further from the brush, such as snow.
Attachments
HSZ 180 UB – Hydraulic Angling kit
Front brush guard – 130cm to control debris discharge for sweepers without collector.
Collector 130cm For KM 45 Series Sweepers
Side Gulley Brush 40cm for KM 45 series sweepers. Hydraulic drive
Electric remote control solenoid valves – Cab mounted
- 12v Electric submersible pump
- Spray nozzels and bar
- Water container mounted on sweeper
-
Water Dust Suppression Kit -200litre for KM45 / KM 50 Series Sweeper
- 12v Electric submersible pump
- Spray nozzels and bar
- Water container mounted 3 point linkage
12v service plug required on vehicle.
