Description
Muthing MU-E Vario
Front or rear mounting for tractors and system vehicles. Professional compact tractors and system vehicles of up to 60 hp require efficient, versatile and robust flail mulchers to carry out mowing and mulching work reliably quickly and economically. At the same time the equipment should be light so as not to restrict the scope of the system vehicles. The MU-E mulcher series was created for this range of tractor
Features & Benefits
- Purposely designed hood in conjunction with high rotor and cutting speeds and a removable shredding bar spreads the shredded material evenly behind the roller giving an excellent Mulching and Shredding Quality
- Made from High Quality Steel QST/S with specially designed Head-Stock Cat. I for Front or Rear mounting, shiftable Mounting position near to the tractor, Head-Stock adaptable to different positions
- Patented removable shredding bar system (Shark Fin)
- Market-leader in foreign object thrown test results
- Gear box with integrated over-run-clutch and through-drive for 540 / 1,000 r.p.m., centred on top of the hood
- P.T.O. shaft; Belt protection with tension measuring slot
- M-Carbide flails with plane and cutting edge made from carbide steel to ensure a long life clean cut and maximum shredding using less power
| Model | WW cm |
Overall width cm |
max. Tractor HP 540 r.p.m. |
Weight kg |
Number of flails |
| MU-E 120 | 120 | 142 | 60 | 280 | 20 |
| MU-E 140 | 140 | 162 | 60 | 300 | 24 |
| MU-E 160 | 160 | 182 | 60 | 330 | 28 |
| MU-E 180 | 180 | 202 | 6 | 360 | 32 |
| MU-E 200 | 200 | 222 | 60 | 390 | 36 |
