Description
The Hydro Luchs LHR-2 is characterised by its particularly narrow, compact and robust design and, with its newly developed design, meets the latest machine operating specifications (EN 709). This makes the LHR-2 extremely manoeuvrable and flexible.
The powerful range of engines makes the Luchs an enduring, powerful all-rounder.
Handlebar inclination can be adjusted without tools with one hand, with quick adjustment (10 positions) from 60 – 130 cm and 180° rotation for front and rear mounting. When the vibration-damped swivel beam is turned 180°, the operating elements change automatically; the operation thus remains the same forwards and backwards.
Newly developed tie-bar base mounted vibration-free on silent blocks for heavy-duty work and continuous use.
Reduction of moving parts, no external parts, well-known Köppl mechanism for more safety and durability due to handy design, improved axle protection with low centre of gravity and high stability.
PTO shaft can be shifted mechanically in the transmission – independent of the hydraulic travel drive by wheel motors with full power transmission.
Hydraulic travel drive with axial piston adjusting pump via strong cast reduction gear with almost wear-free pressure brake clutch.
Including operating hours counter and maintenance interval display.
Implements for Luchs LHR-18
Remote Controller
The remote control gathers all the important functions that are available for your Köppl professional device in one place. The operation remains clear and extremely comfortable.
The speed and direction of the machine is controlled by two separate joysticks. One joystick changes the driving speed and direction. The other joystick controls the machine to the left or right.
On the remote control there are (depending on the implement) toggle switches for the clutch, axle shift, PTO and electrical implement control.
The maximum speed and rpm can also be adjusted on the remote control.
A clearly arranged display and an emergency stop switch complete the complete control of your Köppl device via the remote control.
